| Quantity: | |
|---|---|
| TECHNICAL DATA | ||
| Item | Standard | Result |
| THICKNESS | EN426 | 2.0mm,3.0mm（customized service） |
| SIZE | EN426 | 600x600mm,900x900mm |
| WEIGHT | EN430 | 3.8Kg/2.0mm,5.8Kg/3.0mm |
| ELECTRIC PROPERTIES | DIN51953 ASTM F-150 OR NFPA99 | conductive tile 10^4~10^6 ohm |
| DISSIPATIVE 10^6~10^9 ohm | ||
| DECAY TIME | SJ/T10694-2006(±1000V±100V≤2s) | EQUAL 0.4S |
| CHARGE VOLTAGE | SJ/T10694-2006(ⅠVⅠ<100V) | EQUAL 70 |
| FIRE RESISTANCE | DIN4102 | B1 |
| COMBUSTION PROPERTIES | SJ/T11236-2001(<10S,reach FV-0) | EQUAL 0.35IFV-0 |
| AMOUNT OF ANTI WEAR | SJ/T11236-2001(≤0.020g/cm 21000r) | EQUAL0.014 |
| ANTI-WEAR PROPERTIES | EN660pt2 | ITEN-T<2.0mm3 |
| WHEEL PRESURE | EN425 | No influence |
| RESIDUAL CONAVITY | EN433/DIN51955 | 0.03mm(2.0mm) |
| 0.04mm(3.0mm) | ||
| DIMENTIONAL STABILITY | EN 434 | ≤0.2% |
| COLOR FASTNESS | ISO105BO2 | At least 6 |
| RESISTANCE TO CHEMICALS | DIN423/DIN51958 | Good |
| IMPACT SOUND ABSORPTION | VLI,ISO104,ISO717 | Approx 2dB |
| TEST PARAMETER | ||
| Item | Standard | Data |
| Electrical Resistance(Ω) | SJ/T11236-2001 | Conductive: 10000-1000000 Ω |
| EN1081 | Static-dissipative: 1000000-1000000000Ω | |
| Stating Voltage | SJ/T11236-2001 | 50V , 100V |
| AATCC-134 | |V|<100V | |
| Static Decay(s) | GJB2605-1996 | ≤2 |
| FTM1080-4046 | 0.01 ， 0.01 | |
| Fire Resistance | SJ/T11236-2001 | FV-0 |
| EN13501-1 | Bfl-s1 | |
| Slip Resistance Wet | DIN 51130 | R9 |
| EN13893 | ≥0.3 | |
| Residual Concavity | SJ/T11236-2001 | ≤0.10 |
| EN433 | 0.03 | |
| Effect of Castor Chair | EN425 | No delamination No cracks |
| Formaldehyde Emission | EN717-1 | None |
| Color Fastness | ISO 105B 02 | ≥6 |
| Chemical Products Resistance | EN ISO 26987:2012 | OK |
| Toxic Texting | EN 71-3 | OK |
| GB 18586-2001 | ||
| Smoke Production | GB8624-2006 | ≤750%,min |
| Anti-bacterial | ISO 22196 | Rate I |
| Impact Sound Absorption | EN 0717/2 | Approx 2dB |
| TECHNICAL DATA | ||
| Item | Standard | Result |
| THICKNESS | EN426 | 2.0mm,3.0mm（customized service） |
| SIZE | EN426 | 600x600mm,900x900mm |
| WEIGHT | EN430 | 3.8Kg/2.0mm,5.8Kg/3.0mm |
| ELECTRIC PROPERTIES | DIN51953 ASTM F-150 OR NFPA99 | conductive tile 10^4~10^6 ohm |
| DISSIPATIVE 10^6~10^9 ohm | ||
| DECAY TIME | SJ/T10694-2006(±1000V±100V≤2s) | EQUAL 0.4S |
| CHARGE VOLTAGE | SJ/T10694-2006(ⅠVⅠ<100V) | EQUAL 70 |
| FIRE RESISTANCE | DIN4102 | B1 |
| COMBUSTION PROPERTIES | SJ/T11236-2001(<10S,reach FV-0) | EQUAL 0.35IFV-0 |
| AMOUNT OF ANTI WEAR | SJ/T11236-2001(≤0.020g/cm 21000r) | EQUAL0.014 |
| ANTI-WEAR PROPERTIES | EN660pt2 | ITEN-T<2.0mm3 |
| WHEEL PRESURE | EN425 | No influence |
| RESIDUAL CONAVITY | EN433/DIN51955 | 0.03mm(2.0mm) |
| 0.04mm(3.0mm) | ||
| DIMENTIONAL STABILITY | EN 434 | ≤0.2% |
| COLOR FASTNESS | ISO105BO2 | At least 6 |
| RESISTANCE TO CHEMICALS | DIN423/DIN51958 | Good |
| IMPACT SOUND ABSORPTION | VLI,ISO104,ISO717 | Approx 2dB |
| TEST PARAMETER | ||
| Item | Standard | Data |
| Electrical Resistance(Ω) | SJ/T11236-2001 | Conductive: 10000-1000000 Ω |
| EN1081 | Static-dissipative: 1000000-1000000000Ω | |
| Stating Voltage | SJ/T11236-2001 | 50V , 100V |
| AATCC-134 | |V|<100V | |
| Static Decay(s) | GJB2605-1996 | ≤2 |
| FTM1080-4046 | 0.01 ， 0.01 | |
| Fire Resistance | SJ/T11236-2001 | FV-0 |
| EN13501-1 | Bfl-s1 | |
| Slip Resistance Wet | DIN 51130 | R9 |
| EN13893 | ≥0.3 | |
| Residual Concavity | SJ/T11236-2001 | ≤0.10 |
| EN433 | 0.03 | |
| Effect of Castor Chair | EN425 | No delamination No cracks |
| Formaldehyde Emission | EN717-1 | None |
| Color Fastness | ISO 105B 02 | ≥6 |
| Chemical Products Resistance | EN ISO 26987:2012 | OK |
| Toxic Texting | EN 71-3 | OK |
| GB 18586-2001 | ||
| Smoke Production | GB8624-2006 | ≤750%,min |
| Anti-bacterial | ISO 22196 | Rate I |
| Impact Sound Absorption | EN 0717/2 | Approx 2dB |
